Satlink ST-5150 DVB-S2 DVB-T/T2 DVB-C Combo Digital Satellite Meter

Κωδικός προϊόντος: 01656 Κατηγορία:

Μη διαθέσιμο


Το ST-5150 είναι ένα DVB-S-S2 / T / T2 / C και MPEG-2/4 AVC, H.265 / HEVC συμβατό φορητό πεδιόμετρο χειρός. Με συμπαγές μέγεθος, ελαφρύ, διαισθητικό περιβάλλον εργασίας χρήστη, μεγάλες ώρες λειτουργίας μπαταρίας και πλούσιο σετ χαρακτηριστικών, το πεδιόμετρο παρέχει όλες τις λειτουργίες που απαιτούνται για την εγκατάσταση και την επαλήθευση της υπηρεσίας ψηφιακής δορυφορικής τηλεόρασης, ΕΠΙΓΕΙΑΣ ΛΗΨΗΣ και καλωδιακού σήματος σε κατοικίες ή μονάδες πολλαπλών κατοικιών.

  • Οθόνη TFT LCD 4.3 ιντσών υψηλής ευκρίνειας

249.99 299.90 Με Φ.Π.Α

Μη διαθέσιμο



About this item

  • ST-5150 is a DVB-S-S2/T/T2/C and MPEG-2/4 AVC,H.265(8 Bit) /HEVC compliant handheld combo meter.With it’s compact size,light weight,intuitive user’s interface,long battery operational hours and rich feature set,the meter provides all functions needed for installation and verification of digital Satellite TV service,antenna signal and cable signal to residential homes or multi-dwelling units.
  • 4.3 Inch High Definition TFT LCD Screen; Fully DVB-S/S2/T/T2/C compliant; MPEG2,MPEG4,H.264/MPEG4 AVC,H.265/HEVC hardware encoding. Digital meter for signal strength and quality
  • Supports Auto Scan and Manual Scan; Sound and Light Alarm for Looking Signal; Auto Calculate Angle of AZ,EL
  • Supports DISEQC 1.0/1.1/1.2 ,Unicable, 0/22kHz Tone; Speaker Integrated; Support both AV out and AV in; Support both HD-MI out
  • 7.4V/2600mAh Li-Ion Battery included; Adapter Output: DC12V/1.2A,Input:100-240VAC 50/60Hz; Power Consumption: Max, 10W; Software upgrade via USB port, Easy to carry

Transmission Standards:


Satellite Input / Demodulation:
Connector Type: F Type
Input Frequency: 950 to 2150 MHz
Signal Input Level: -65 to-25 dBm
Band Switch Control: 22KHz
LNB Supply: 13V/18V,Imax 400mA
Demodulation Type: QPSK, 8PSK, 16APSK
Symbol Rate: 2 < Rs < 45Mband (SCPC/MCPC)

DVB-T / T2 / C Input / Demodulation:
Connector Type: Female Type
Input Frequency: 48 to 862 MHz
Signal Input Level: -79.5dBm (MAX)
ANT Supply: 5V,12V/24V Imax 100mA
Demodulation Type: QPSK, 16PAM, 64QAM, 256QAM

LCD Features:
LCD Type: TFT Transmissive
Number of Dots: 480x(RGB) x272
Active area (WxH): 95.04mmx53.86mm
AV output interface:
Connector Type: 3.5 mm jack
Video Output: CVBS
Audio Output: Stereo Audio L/R output
Audio/Video Processing:
Video decompression: MPEG-2 MP @ HL,MPEG-1 Decoding, MPEG-4 ASP @ L5 HD resolution, H.264 MP&HP @ L4,H.265/HEVC, HW JPEG decoding
Resolving rate: PAL-25 frame @ 720*576, NTSC-30frame @ 720*480
Signal compatibility: Support conversion for different video formats
Video Format: 4:3, 16:9, By Pan & Scan and Letter Box conversion
Audio Decompression: MPEG-1 Layer I/II, MPEG-2 Layer I/II
AUDIO Output: Stereo, Mono, R/L
Data Service Port:
Connector: USB
Data Protocol: USB2.0 interface
File Management System: NTFS, FAT32, FAT16
File Format: wma, mp3, mp4, avi, jpp, bmp, img
Power Supply:
Li-lon Battery: 7.4V/2600mAh (The machine behind labeling shall prevail)
Adapter: Output: DC12V/1.2A, Input:100-240VAC 50/60Hz (Will be subject to actual configuration)
Power Consumption: Max,10W
Size(WxDXH): 170mm x 120mm x 40mm
Net Weight: 1Kg

Package Included:

  • 1 x ST-5150 Digital Satellite Meter;
  • 1 x AV cable;
  • 1 x Power Adapter
  • 1 x Silicone case;
  • 1 x Straps;
  • 1 x User Manual(English)

User’s Manual – Dowload  here
